UKFC207D1
Информация о продукте
Модель подшипника
UKFC207D1 X AS3S
Базовые нагрузки
| Cr | 25.7 | kN | Basic dynamic load rating |
| C0r | 15.3 | kN | Basic static load rating |
Другие
Included products
| Bearing | UK207D1 | Bearing | |
| Housing | FC207D1 | Housing |
Associated products
| Adapter sleeve | H2307X | Adapter sleeve |
Nominal Dimensions
| d | 30 | mm | Bore diameter |
| L,H | 135 | mm | Overall length |
| H3 | 90 | mm | Outer diameter of Spigot Joint |
| J | 110 | mm | Pitch diameter of attachment bolts |
| J1 | 77.8 | mm | Distance between attachment bolts |
| N | 14 | mm | Diameter of attachment bolt hole |
| A3 | 8 | mm | Height of of Spigot Joint |
| A2 | 11 | mm | Flange width |
| A1 | 26 | mm | Flange width |
| A | 34 | mm | Base width |
| A0 | 42.5 | mm | Overall width |
| B,B1,B2 | 43 | mm | Width of inner ring |
| F | 40 | mm | Diameter of housing abutment |
Mounting information
| G | M12 | Bolt size |
Масса
| mass | 1.7 | kg | Mass approx. |
